The Electromagnetic Focused Shockwave Therapy Device is an advanced, non-invasive treatment system that combines cutting-edge electromagnetic technology with intelligent focusing principles. Designed for human musculoskeletal and joint rehabilitation as well as veterinary care, it delivers precise energy to targeted tissues, from superficial to deep layers, even reaching hidden pain points that are difficult to detect manually.
Energy Conversion
The internal electromagnetic generator generates pulsed electromagnetic fields, converting electrical energy into mechanical shockwaves via high-speed diaphragm movement.
Focused Transmission
Shockwaves are focused through a specially designed reflector, producing a high-energy-density beam that precisely targets the lesion with stable energy delivery.
Biological Effects
Stimulates local tissues, enhances blood circulation, activates osteoblast activity, and accelerates inflammation absorption to promote rapid tissue repair.
| Parameter | Value |
|---|---|
| Model | A69 |
| Display | 15.6" Touch LCD |
| Power Supply | AC 110V-220V ±10% |
| Rated Power | ≤500VA |
| Applicator Heads | 6 silicone heads (interchangeable) |
| Maximum Penetration Depth | 0-8 cm |
| Treatment Duration | ~10 minutes per session |
Focused Shockwave (F-SWT): Energy is concentrated at a specific point, penetrating deep into tendons and joints. Ideal for deep tissue lesions like frozen shoulder and knee arthritis.
Radial Shockwave (R-SWT): Energy disperses over the surface, acting on superficial muscles. Suitable for myofascial pain and general muscle tension.
